2 Stage Hydraulic Power Pack

2 Stage Hydraulic Power Pack

whyps whyps
May 5, 2016 - 15:13 Updated: May 3, 2025 - 15:14
2 Stage Hydraulic Power Pack

Brand new WILLIAMS. Use for hydraulic log splitters. 2 stage, 8 piston hydraulic pump provides both large volume oil delivery and high pressure. Requires less than one-fourth input power than conventional 1 stage units thus more economical operation. Includes pump, 4 way control valve and reservoir in one compact unit. Drive either direction.    SPECIFICATIONS  8 piston pump  High vol., low press:    6 GPM to 12 GPM @ 750 PSI  Low vol., high press:   1.5 GPM to 3 GPM @ 3000 PSI  Speed range 600-1200 RPM  Reversible Rotation  Displ. 2.64 cu. in./rev.  Cyl. ports 1/2" NPT  Dbl. acting valve  Shaft 1" diam. x 1 3/4" w/ 1/4" keyway  Requires 5 HP @ 600 RPM input  Reservoir 15 qts.  11" x 8 1/2" x 8 1/2"  Shpg. 68 lbs.
