5 Bolt Wheel Hub For 1-1/4 Tapered Shaft

New, machined casting five bolt wheel hub with brake drum. Ideal for mounting wheels onto hydraulic motors with 1-1/4" tapered shaft.    SPECIFICATIONS  Wheel Studs 5  Wheel Stud Size 1/2"-20 thread  Bolt Circle 4-1/2"  Hub 1-1/4" tapered w/keyway  Keyway Size 5/16"  Bore Taper 1-1/2" per foot  Thru-hub Length 1-29/64"  Brake Drum Diameter 6.299"  Size 7-3/8" dia. x 2-7/16"  Shpg. 10 lbs.
