6:5 Valve Controller

The 6 Inputs/5 Outputs Valve Controller adds multi-functional hydraulic valve control to Axiomatic’s line of machine controls.    Simulink software development allows OEM designers to program the device for specific applications  Provides precise, repeatable control of five proportional or on/off solenoids over a SAE J1939 network  PWM signal inputs or analog voltage or current inputs are accepted for interface to a PLC, Engine Control Module or command  potentiometers  Multiple switched inputs are provided to suit a range of applications, and each can be configured to measure the input value, and send the data to a SAE J1939 CAN network  Any output on the controller could be configured to use any of the on-board inputs as either a control signal or an enable signal, instead of taking the control information from the CANbus  Diagnostics messages are provided over the CAN network for the status of inputs or outputs  Settings are user configurable via a Windows-based Electronic Assistant tool  Rugged power supply interface accepts 12 or 24V DC nominal for battery powered machine applications  Features IP67 rating and is suitable for use in outdoor and high vibration environments  Includes CE mark  Operates from -40 to 85 C
