Hydraulic Fluids: The Critical Role of Flushing Rigs in Automated Systems

In the age of high-speed automation, precision is the key. We depend on hydraulic systems to supply the power used by robotic machines, CNC equipment, and injection moulders. However, there is a silent killer lurking in those systems. It's particles of contamination.

The smallest of particles, the kind you can't be able to see with your naked eye, can cause an utterly catastrophic failure of a component, unforeseen downtime, and huge financial loss. Here's the point: the flushing equipment comes in, acting as the ultimate deep-cleaning mechanism to protect industrial health.

The Problem: The "Built-in" Enemy

When a brand-new automated system is put in place, or one is fixed, it's not "clean" by default. Contamination can enter the system via several routes:

  • The initial assembly: Silica and metal shavings from seals, as well as welding slag.

  • Maintenance Fibers and dust are created when a hose is changed.

  • System wear: Metal flakes that are microscopic, produced by the movement of parts.

In an automated system where precision is measured by microns, these particles behave like Sandpaper, which can erode valves and shut off pumps.

What is a Flushing Rig?

Consider a flushing rig as a powerful, outside "dialysis device" that is used to flush your hydraulic systems. Contrary to standard onboard filters, which are designed to keep the system clean in normal use, a flushing rig is a specific unit designed to cleanse the system according to the specific standards (like ISO 4406).

How it works: Turbulent Flow and Laminar Flow

The key to a successful flush isn't simply moving oil, but rather the speed.

  • Laminar Flow When operating normally, the oil is able to move effortlessly. Particles tend to be deposited in dead zones and "stick" onto the walls of the pipe.

  • Turbulent Flow: The flushing system pumps liquid at an increased flow rate compared to the pump used by the standard system. This results in "turbulent flow," which removes particles from the inner walls of the pipes and transfers them to high-efficiency filters.

To determine the efficacy of the flush, engineers typically examine what is known as the Reynolds Number ( Re). To ensure that turbulence can eliminate contaminants, the objective is usually a Reynolds Number higher than 4,000:

Re = rho v D/mu

Where:

  • Rho is the density of fluids.

  • V is the speed.

  • D is the diameter of the pipe.

  • mu is the dynamic viscosity.

The Benefits of Automated Environments

Benefit The Impact of HTML0 on the Production
Component Longevity Increases the lifespan of expensive servo valves as well as actuators.
Predictable Performance eliminates "jerky" motions in robotics due to the valve's siltation.
Reducing Guarantee Claims Make sure that systems supplied to clients comply with the strict standards for cleanliness.
Data-Driven Maintenance Modern rigs have laser particle counters, which give a "birth certificate" of the cleanliness.

Implementation: When to Flush?

Flushing is not an "once-in-a-decade" occasion. In highly automated settings, it is essential to do so during:

  1. After-Installation Prior to powering up.

  2. Principal Component Failure: When a pump or motor "grenades" and passes steel through the line.

  3. Routine Overhaul:s In the context of a routine maintenance program every couple of years.
