Gates Industries First Multi Purpose Hose

Multi Master™ SD MegaFlex® hose
Gates recently launched a multifunctional hose, SD MegaFlex®. This multi-purpose hose will serve the needs of three distinct markets: fuel transfer, hydraulic return and suction lines, and 20R5 coolant applications. The Multi Master™ SD MegaFlex® line is the first-of-its-kind to simultaneously meet SAE 100R4, SAE J30R5, and SAE J20R5 requirements. It has a 1:1 bend radius, an ARPM Class A tube, and is also MSHA compliant.

The Multi Master™ SD MegaFlex® hose provides customers with a solution to a broad range of demanding applications. The nitrile tube has excellent oil and fuel resistance and is compatible with air, water, and coolant. Its corrugated chloroprene cover and steel helix reinforcement give it superior 1:1 flexibility and make it effectively kink-free. The hose can be used from -40°F to +250°F (-40°C to +121°C) in both suction and discharge applications.

Features
Exceeds THREE industry specs – fuel transfer standard J30R5, the hydraulic return line standard SAE 100R4, AND the coolant standard J20R5.

Gates MegaFlex® technology enables a true 1:1 bend radius for unparalleled flexibility without kinking.

Full suction capabilities.

Excellent oil and fuel resistance, while also being compatible with water, air, and lubricating oils.
