Parker ASL250-01 Series Hydraulic Pump

Parker Autoclave Engineers ASL250-01 series pump is capable of pressures up to 38,400 psi and offers flow rates up to 48 in³/min. Being air driven, the pump is explosion-proof and safe for use in hazardous areas. Pumps are used for pumping oil, water, or oil/water mixtures.

All AE pumps are designed standard with stainless steel wetted parts, making them ideal for most applications.

Features:
Standard, Air Operated Liquid High Pressure Pump

6” Single-Acting, Dual Piston Air Drive

Air to Pressure Ratio: 1:265

Stainless Steel Plunger Utilizing a Proprietary Multilayer Carbon-Based Coating with Diamond-Like Carbon Exterior Layer

3 times the Hardness of Stellite with a Coefficient of Friction Equal to or Less Than PTFE!

Air Drive Pressure Range: 15-150 psi (1-10 bar)

Volume Displacement per Stroke: 0.22 in³ (3.6 cm³)

Maximum Outlet Pressure: 38,400 psi (2648 bar)

Isolation (distance) chamber to protect air-drive section from high pressure seal leakage is optional
