3/4" SAE 100R13 Hydraulic Hose Assembly

3/4" SAE 100R13 Hydraulic Hose Assembly

R13 hose is suitable for hydraulic fluids on mineral oil and synthetic oil basis (HL, HLP, HLPD, HVLP), oil-water-emulsions (HFAE, HFAS, HFB), water-glycol liquids (HFC), vegetable and mineral oil based lubricants, cooling water, and compressed air. Also generally suitable for biologically degradable hydraulic liquids (HETG, HEPG, HEES) however limited by fluid additives.

Technical Specifications
Tube: Oil-resistant synthetic rubber
Reinforcement: Six braids of high tensile steel wire (sizes -12 and -16 have four layers)
Cover: Oil and Abrasion-resistant synthetic rubber
Temperature: -40°F to +250°F

This made-to-order hose assembly is available with W Series Bite-To-The-Wire Hose Fittings (indicated by a W suffix at the end of the part number). Select your required fittings and length below. Click Update Price to view your total cost with the selected options. When measuring your custom hose assembly, measure fitting to fitting on straight assemblies, and to the center line of a 90° or 45° fitting.

Cost per foot: $11.73
Assembly fee: $10.00
