Continental PC 150 Series Crimpers

Continental PC 150 Series Crimpers

Continental PC 150 Series Crimpers

Continental PC 150 Series Crimpers
The new PC 150 comes with more power and can make quality hose assemblies, quickly and easily. The open design and removable pusher and “slide in” die configuration allows for good visibility and easy loading of dies and hose assemblies. Crimp diameter can be set and controlled by an easy-to-read micrometer.

Designed to handle higher volumes in a shop environment, the PC150-2 includes the crimper and 2 HP pump on a common base, pressure plate, compression ring, die ring pusher, stop/start remote pendant switch, metric micrometer, adjustable coupling stop, adjustable retraction stop, and work light. The optional PC150-1 includes all the components of the PC150-2 and a 1 HP pump.

Features
Easy-to-read, fully adjustable metric micrometer allows precise setting of crimp diameters to an accuracy of +/- 0.1 mm

Open design with vertical feed for good operator visibility

Removable pusher and spring-loaded die set for easy loading

80-ton cylinder

Automatic shut-off for precise crimps

Adjustable retraction stop limits ram retractions for quick repetitive crimps

Adjustable coupling stop for accurate, repetitive positioning of the assembly inside the dies

Two-piece, “slide in” die set for easy installation

Common base for bench mounting

Color-coded die sets to speed die selection and set-up

2 HP, 220V pump

Pneumatic activation (no electric wires) of remote pendant switch

Capability: 1/4" through 1½" ID, 2-wire braid hose and 4-spiral hose with all coupling styles and most bent tubes

Power Source:

2 HP 220V AC, single phase, 50-60 Hz electric pump (PC150-E2Pump) for PC150-2 crimper

Optional 1 HP 110V AC, single phase, 50-60 Hz electric pump (PC125/150-E1Pump) for PC150-1 crimper

Oil Capacity: 1 gallon
Mounting: Crimper and pump installed on plate
Dimensions: 32" deep x 16.5" wide x 29" high
Weight: 275 lbs
