Eaton AxisPro™

Eaton AxisPro trade
Course Code : Hyx_ILT_APRO
Date : December 14-15, 2017
Course Fees : $564

Location : Maumee, OH<
Duration : 2 Days

This two-day course is designed for those individuals who have intimate working knowledge of high performance proportional valves and how they should be applied in the field of electro-hydraulics.  The foundation of this course assumes the attendee is familiar with Servo Proportional Valve Technology; PID theory and application and principles of open and closed loop systems as it applies to electro-hydraulics.  The AxisPro valve levels one through four are discussed, identifying key features and benefits with heavy concentration on the level 2 and 3 valve.  In addition to a classroom setting, attendees will work hands-on in a laboratory environment with AxisPro utilizing Eaton’s ProFx Configure software.  The final measure of this course is the effective commission of an AxisPro valve which includes the exporting and importing of valve parameters and performing basic valve functions Prerequisites ndustrial Hydraulics or Mobile Hydraulics course; CANbus Basics; Electro-Hydraulics Maintenance and Troubleshooting course or equivalent advanced electro-hydraulic training

Who Should Attend : This course is appropriate for personnel who have working knowledge of high performance proportional valves and how they should be applied in the field of electro-hydraulics. Attendees should already be familiar with Servo Proportional Valve Technology; PID theory and application and principles of Open and Closed loop systems as it applies to electro-hydraulics opics Covered: Pro-FX Configure Software
Initialization
Operation
Data Plotting
VSC Mode<
DPC Mode
DSC Mode
DFPC Mode

Completion Requirements & ;Students will be required to attend and participate in all sessions, exercises, and assignments.  In addition, successful completion of this course will require passing a comprehensive written exam with a score of 70% or higher.
