What factors determine cylinder stroke length and mounting type?

The length of the stroke and the mounting style is determined by the travel distance required as well as the load and side-thrust requirements the cylinder has to withstand and the cylinder's envelope for its installation. The length of the stroke is calculated based on the linear distance required plus a safety margin and the mounting type is chosen according to how the forces are transferred into the frame of the machine, whether the load is angular or aligned and the amount of deviation or vibration the system is able to withstand.

The wrong stroke length results in inadequate travel or wasted envelope space, as well as the risk of buckling from excessive rod extension. The wrong type of mounting results in premature rod seal wear, fatigue of the trunnion pin, and bent rods caused by side loading. Making sure both are correct in the design phase will prevent costly modifications and field failures. This guide explains the engineering aspects that drive every decision.

Understanding stroke length

Stroke length is the longest linear distance that the piston travels through the barrel from fully retracting until fully stretched. It may sound like a straightforward measurement, however the stroke choice is influenced by the strength of the column, cost of the cylinder and the geometry of the machine in ways that may catch unexperienced specifyors off guard.

Travel for application requirements

The point of departure is always the exact distance that the load has to travel. It is calculated directly from the mechanical design of the machine - the throw of an axe and the lift height of platforms and the swing arc the boom (converted to linear equivalent) or the distance to clamp the fixture. Engineers generally add 5-10% to the calculated travel in order to accommodate the tolerance of mounting, expansion and thermal and wear during the life of the cylinder's service.

Risk of buckling and column strength

Longer strokes indicate longer rods extended during load, thereby increasing the possibility of bucklingwhich is when the rod bends to the side under compressive force instead of straightening. Buckling risk is governed by rod diameter, unsupported length, mounting style, and end-load magnitude, and is typically checked against Euler's column formula or manufacturer-published buckling charts. A cylinder that is specified as having an excessively long stroke in relation to its diameter may require a longer rod, a stop-tube that is added to cut down on length unsupported at full extension or switching to a multi-stage or telescopic design for a cylinder.

Retracted length and envelope

Each stroke length is added to the length of the cylinder's retract because the barrel has to be large enough to accommodate the piston during full stroke, with cushioning and cap the thickness. In machines with limited space the length of the retracted cylinder can be the primary factor often requiring a change towards the use of telescopic cylinders which incorporate multiple stages in order to create longer strokes inside a envelope, which comes however, this comes at a cost: more expensive prices and less side load capacity.

Deceleration and cushioning

Long-stroke cylinders carrying massive loads at a high speed require cushioning at either or both ends in order to slow the piston prior to reaching the cap at its end, thus avoiding sound and impact damage. The length of the cushioning takes up part of the barrel and stroke length, and therefore must be included in the design rather than being adding it in the last minute.

Understanding the mounting type

The type of mounting determines the way in which the cylinder transfers force to the surrounding structure and the amount of angular moving lateral it can support when in operation. The correct mounting method shields the rod and seals against side-loading that doesn't belong in the work.

Mounts that are fixed (centerline) mounts

Fixed mounts such as flange or foot styles- anchor the cylinder with rigidity around its axis. They are suitable for applications where the path of load is straight and in alignment with the cylinder's centerline through the entire stroke, like straight-line pushing or vertical press applications. Mounts with flanges (front and rear) can handle the largest thrust loads as force flows directly through a wide and rigid interface, which makes them a common feature on high-tonnage presses as well as injection molding machines.

Pivoting mounts

Pivoting mounts, both trunnion and clevis modelslet the cylinder body to turn slightly when the geometry of the load changes during the stroke. This is vital when the cylinder is driving the swinging or rotating component like a lift arm or tailgate body. Trunnion mounts put pivot pins onto the cylinder body as a whole, whereas Clevis mounts utilize pin joints on the cap's end. The right choice is determined by what the purpose of the pivot to be near the center of mass of the cylinder (trunnion is better to handle dynamic load) or at the far end (clevis more common and simpler for the field of mobile hydraulics).

Tolerance for side-loads and misalignment

Each type of mounting has a specified tolerance for load off-axis and over-loading is among the most frequent reasons for premature seal failures and scourred rod surfaces. Mounts for feet, for instance can be susceptible to bending moment if the cylinder isn't aligned to the direction of load because the feet that are used to mount sit outside the centerline. Applications that have any potential for deviation or vibration travel should be resorted to pivoting mounts, or self-aligning couplers instead of forcing an unsupported mounted to absorb the side thrusts it was not designed to absorb.

The duty cycle and exposure to vibration

Mobile and off-highway equipment is subject the cylinders to continual vibration and shock, which means trunnion or clevis mounts featuring bushings and pins made of hardened steel the preferred choice as they distribute dynamic loads over a pin joint than a bolted and rigid interface that could become loose or break when repeatedly hit. Industrial stationary equipment that has steady linear load paths depends more securely on foot or flange mounts, which are less expensive and facilitate the installation process by allowing for alignment.

The strokes are matched, and the mounting is matched to the application.

In the real world, stroke length and the type of mounting aren't selected in isolation; they are interconnected. A cylinder with a longer stroke mounted on a pivoting mount for instance, requires more focus on buckling due to the fact that the clevis pin or trunnion allows for some flexibilities at the base that an flange-mounted cylinder with a rigid structure will not. Similar to the case with applications that have restricted side-load tolerances, they typically require designers to design shorter strokes with bigger rod diameters. This means that they trade some travel distance in exchange for durability of the column and sealing. The most secure method is to trace out the entire journey and load path first, and then choose a strokes and then mount against side-load and buckling charts from the manufacturer instead of focusing on each specification as a separate spec.
