Bosch Rexroth 2-way cartridge valve

Bosch Rexroth 2-way cartridge valve
Bosch Rexroth  all New Hydraulic Products. The 2-way cartridge valves type LC2A are designed in compact modular design and basically consist of cartridge, socket and intermediate cover as fixed functional unit and a control cover type LFA that is part of the Rexroth standard logics program. This control cover establishes the connection with the pilot control valves and/or other hydraulic elements and thus integrates the most different functions - irrespective of the basic assembly.

Features


• Actively controllable 2/2 directional cartridge valve ("two-level active logics")

• Modular design, flexible circuit set-up

• Installation bore according to ISO 7368

• Energy efficiency due to flow-optimized geometry

• Leakage-free due to integrated shaft sealing

• Spool position monitoring "closed" and/or "open" oranalog (can also be retrofitted)

• BG certification

• Increased operating pressure 450 bar upon request
