Hydraulic motor

Hydraulic Motor Specifications
Brand: White Drive Products

Model: 157125W31N9AAAAA

Family: WP

Displacement: 7.6 cu. in. / rev.

Motor Type: Gerotor

Rotation: Reversible

Performance
Pressure:

Continuous: 2320 PSI

Intermittent: 2540 PSI

Torque:

Continuous: 2285 in-lbs.

Intermittent: 2460 in-lbs.

Speed:

Continuous: 559 RPM

Intermittent: 599 RPM

Flow:

Continuous: 16 GPM

Intermittent: 20 GPM

Design & Mounting
Mount: Four-bolt wheel

Shaft:
28.5 mm diameter tapered x 4.69" long
Includes 3/16" key and threaded end with castle nut

Ports: SAE 10 side ports (aligned)

Case Drain: None

Size: 3.35" x 4.17" x 4"

Shipping Weight: 18 lbs.
