Hydraulic rotary actuators

The Hydraulic Rotary Actuators MRPH are designed for precise and efficient rotational motion in various industrial applications. Manufactured by Mindman Industrial, these actuators feature a compact design and are constructed from anodized aluminum alloy for enhanced durability and a polished aesthetic appeal. The pinion and rack mechanism is made from carbon steel, which significantly reduces backlash, ensuring smooth and reliable operation.

Key specifications include:

• Tube I.D.: 32 mm and 40 mm
• Standard Rotation: 90±5° and 180±5°
• Rotating Shaft Diameter: 24 mm and 28 mm
• Medium: Filtered air (with or without lubrication)
• Maximum Operating Pressure: 3.5 MPa
• Ambient Temperature Range: -10 to +60°C (non-freezing conditions)
• Maximum Allowable Axial Thrust: 12 kg and 20 kg
• Additional features include a rotation adjustment screw for fine-tuning the movement and an optional
• LN01P sensor switch for enhanced control and monitoring.

These actuators are particularly suitable for applications requiring precise positioning and robust performance in harsh environments. For more details, you can visit the product pages on Mindman and Fonray.
